Elevate Your Business with Reliable Cable Ties
Unleashing Precision and Durability Your Reliable Cable Tie Solutions
Unleashing Precision and Durability | Material: | Nylon66(UL) |
| Operatiing Temp: | -40℃ to 120℃ |
| Flammability Rating: | UL 94V-2 |
| Color: | Natural/Black |
| Application | With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building. |
| Material: | Nylon66(UL) |
| Operatiing Temp: | -40℃ to 120℃ |
| Flammability Rating: | UL 94V-2 |
| Color: | Natural/Black |
| Application | With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building. |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | ||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | ||
| 5.5x100 | 5.5 | 100 | 4" | 15 | 6.5-7.2 | 0.5-8 | 62 | 28 | |
| 5.5x150 | 5.5 | 150 | 6" | 30 | 6.5-7.2 | 0.5-8 | 62 | 28 | |
| 5.5x210 | 5.5 | 210 | 8.2" | 45 | 6.5-7.2 | 0.5-8 | 62 | 28 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | ||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | ||
| 4.6x170 | 4.6 | 170 | 6.7" | 45 | 6-6.5 | 0.5-8 | 50 | 22 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | ||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | ||
| 4.6x160 | 4.6 | 160 | 6.3" | 40 | 6-7 | 0.5-8 | 50 | 22 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | |||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | |||
| 4.6x220 | 4.6 | 220 | 8.6" | 50 | 6.5-7.4 | 0.5-8 | 50 | 22 | X16 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | ||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | ||
| 4.6x165 | 4.6 | 165 | 6.5" | 40 | 6.5-7.2 | 0.5-8 | 50 | 22 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | ||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | ||
| 5.5x160 | 5.5 | 160 | 6.3" | 40 | 7x12mm | 0.3-3.2 | 62 | 28 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | Panel thickness | Min.Tensile Strength | ||
| mm | mm | inch | mm | (mm) | (mm) | ibs | kgs | ||
| 7x165 | 7 | 165 | 6.5" | 40 | 7x12mm | 0.3-3.2 | 113 | 50 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | |
| mm | mm | inch | mm | (mm) | ||
| 4.6x160 | 4.6 | 160 | 6.3" | 40 | 5 | |
 |
Item No. | Width | Length | Max.Bundle Dia. | Hole Dia. | |
| mm | mm | inch | mm | (mm) | ||
| 5.2x170 | 5.2 | 170 | 6.7" | 45 | 5-6 | |
